SC582 Fiberglass Fabric
Category: Fiber Glass
Overview
SC582 is a medium-duty double-side aluminized fiberglass fabric providing bidirectional radiant heat reflection. The 30-micron aluminium foil is laminated on both faces of a plain-weave E-glass base fabric using heat-resistant adhesive, delivering ≥92% infrared reflectivity. Suitable for outer facing of removable insulation jackets and HVAC duct insulation.
Technical Specifications
| Thickness | 0.45 mm |
| Weight after Treatment | 575 g/m² |
| Weave | Satin 4END |
| Setting per Warp | 18 END/CM |
| Setting per Waft | 12.6 END/CM |
| Tensile Strenght Warp | ≥180 N/2.5CM. |
| Tensile Strenght Weft | ≥130 N/2.5CM. |
| Length | 50 m. |
| Width | 1.5 m. |
| Appearance color | Grey, Other requirement |
| Service Temperature | Up to 550°C |
| Melting Point | 1000°C |
Applications
- Removable insulation jacket outer facing
- HVAC duct insulation wrap
- pipe insulation covers
- industrial heat shields
- fire curtains
Key Features
- ≥92% bidirectional heat reflectivity
- waterproof aluminium surface
- oil and moisture resistant
- sewable and grommetable for fabrication
- non-combustible
Note: Product specification sheet pending. Contact STICO for data sheet.
For technical inquiries & custom orders: supakorn@stico.co.th | Tel: 02-035-9589
