Air Diffuser
Category: Diffuser
Overview
Air diffusers distribute conditioned supply air into occupied spaces, promoting uniform temperature and velocity distribution while minimizing drafts and noise. The adjustable vane or fixed-pattern core controls throw direction and spread angle, allowing the airstream to mix with room air before reaching the occupied zone. Available in square, round, and linear slot configurations for flush ceiling, exposed plenum, or sidewall installation.
Technical Specifications
| Type | Square / Round / Linear slot diffuser |
| Body Material | Powder-coated aluminium (RAL 9010 white standard) |
| Core/Vane Material | Aluminium / Stainless steel option |
| Neck Diameter | 100 – 600 mm (round); custom rectangular |
| Face Size | 225×225 – 625×625 mm (square) |
| Air Volume | 30 – 2,000 m³/h per diffuser |
| Throw Pattern | 1-way / 2-way / 3-way / 4-way (adjustable) |
| Throw Distance | 2 – 12 m |
| Pressure Drop | 5 – 60 Pa (at design volume) |
| Noise Level | NC 25 – NC 40 |
| Standard | ASHRAE 70 / ISO 5219 / SMACNA |
Applications
- Commercial office and retail HVAC supply
- hotel and residential ceiling air distribution
- clean room and hospital supply air
- data centre precision air conditioning
- school and university ventilation
- industrial light-duty air supply
Key Features
- Adjustable vane pattern for flexible throw direction
- low noise level (NC 25–40)
- powder-coat finish compatible with all RAL colours
- easy plenum box or duct neck connection
- available with opposed-blade damper for volume control
- compatible with swirl, VAV, and CAV terminal units
For technical inquiries & custom orders: supakorn@stico.co.th | Tel: 02-035-9589
